Photoelectric smoke detection with an audible and visual warning at home. Add connected alerts through your configured ORVIBO system.
Tech specsWhat you need
- Battery power and indoor ceiling mounting.
- Placement checked against the supplied alarm’s installation guidance.
- An ORVIBO Zigbee setup for connected alerts; the alarm also sounds locally.
Two ways to bring it to your attention
How the SF30
raises an alarm.
- At the detector
- The SF30 sounds its local alarm and gives a visual indication when smoke is detected.
- Through your system
- An ORVIBO Zigbee setup can provide configured connected alerts.
Planned for your home
Placement and upkeep
Ceiling placement follows the supplied manufacturer guide. Keep testing and cleaning part of your routine.
Placement & setup
For indoor ceiling mounting, away from steam, routine cooking smoke, lights and ventilation outlets. Do not install in bathrooms or other damp areas. The supplied guide calls for testing at least weekly and dust removal at least annually.
Smoke Sensor Pro
Technical specifications
Dimensions, connections and installation details.
Model / version
SF30
SF30 smoke sensor for indoor ceiling mounting.
Product code- 9.09.01000226
Dimensions & fitting
- Diameter × height
- Ø90 × 37 mm
- Installation
- Indoor ceiling mounting; screws recommended by the manufacturer
Power & connection
- Power supply
- DC 3 V
- Wireless connection
- Zigbee · 2.4 GHz
- Low-battery warning
- Audible and visual indication
Use & environment
- Detection
- Photoelectric smoke detection with local audible and visual alarm
- Alarm sound pressure
- ≥80 dB, measured 3 m in front of the detector
- Operating temperature
- −10–55 °C
- Routine care
- Test at least weekly; remove dust at least annually
Product documentation
Smoke Sensor Pro
Plan smoke detection with your home in mind.
We’ll discuss placement, connected alerts and the supplied detector’s guidance.
