Open or close your curtains with a wall control, a schedule or a room scene.
Tech specsWhat you need
- A compatible track and wired power at the motor position.
- Track layout, recess space and fabric weight checked together.
- A configured ORVIBO Zigbee setup for connected control.
Around your day
Curtains that follow
your day.
Wake up to daylight.
Set an opening schedule around the way your day begins.
Close your curtains for the evening.
Bring compatible curtains into your evening scene.
Change your mind.
Use a compatible wall control when you want something different.
Schedules and scenes require compatible connected controls and configuration.
The mechanism
Behind the curtain.
The motor works with a compatible curtain track. The right combination starts with your window, your fabric and the space available.
Planned together
Start with
the window.
Share your window dimensions or a plan. We’ll check the track, curtain weight and power position before choosing the installation.
- Track & recess
- The track layout, curtain stack and space above the window.
- Fabric & weight
- The full curtain weight and the way it will open.
- Power & control
- Wired power at the motor, plus compatible Zigbee control.
What we check before installation
The W45CZ motor body is listed at 310 × 68 × 50 mm. This does not include the track or the gathered curtain. The supplied revision, track geometry and fabric load are confirmed together before installation.
Curtain Motor
Technical specifications
Dimensions, connections and installation details.
Model / version
W45CZ
W45CZ reference dimensions. Nova confirms the motor revision and track layout before planning the curtain recess.
Product code- 9.13.01000058
Dimensions and installation
- Motor body dimensions
- 310 × 68 × 50 mm (manufacturer product-list dimensions)
- Track and recess allowance
- Confirm track layout and the space for the gathered curtain separately.
Power and connectivity
- Power supply
- 100–240 V AC · 50/60 Hz
- Communication
- Zigbee
Curtain load
- Published maximum load
- 40 kg for an 8 m curtain, per the exact-code product-list entry
Product documentation
- ORVIBO · W45CZ in the 2022 product list (English · Scribd · downloads require sign-up)
Curtain Motor
Plan your curtain control.
A new build or a room you already love. Let’s plan the right curtain control.
